PSP Products Inc. KGC-277 For Generac 277/480V 3ph ATS Sensing to 2-Wire Start Generator Converter

PSP KGC-277 Specs *Click*

PSP Generac Install Guide *Click*

The interface provides the necessary voltage sensing, timing functions and switching circuits required for automatic operation. This allows a 2 wire start generator to be installed without having to change the transfer switch or wiring between the transfer switch and generator.

• Connects to any 2-wire start generator
• Utility loss timer selectable 5 sec. or 30 sec.
• Generator cool-down selectable 10 sec., 300 sec., or 600 sec.
• Utility return transfer timer selectable between 30 sec., 120 sec., or 600 sec.
• LED indicator confirms utility or transfer mode
• 2 year warranty
• Optional weekly exercise timer – Item# DTS-1

**If using a Generac RTS style Transfer switch for 277/480v WYE or 480v Delta, the switches come standard with two step-down transformers taking the system voltage down to 240v.(See Photo)

**Most installs using the Generac RTS require to use the KGC-240**

If you are using any other transfer switch other than a Generac RTS, then the KGC-277 will be the device.
